Bay Freestanding Fireplace

Add a classic source of heat to your family's favorite gathering place.

The Bay fireplace can turn your living space into a warm and cozy environment. It's economical, environmentally friendly, and attractive, the Bay fireplace has proven to be exceptional at heat distribution when placed in the main living area.

As electricity costs rise, the fireplace is becoming a popular home heating source. It usually costs less to purchase some firewood for your efficient wood burning fireplace than to heat your home using the local utility company

• Tested to UL127 & UL391 Standards
• Greater Heat Output & High Efficiency
• Exceptional Durability
• Removable Ash Pan is Standard
• Large Burn Chamber


EnergyKing Bay Freestanding Fireplace Specifications:

EnergyKing Bay 2012 Model

• Overall Dimensions (H x W x D): 35" x 33" x 24"
• Required Hearth Opening (H x W x D): N/A
• Shipping Weight (approx.): 510 lbs.
• BTU Capacity* (approx.): 45,000 BTU
• Heating Area* (approx.): 1,500 Sq Ft
• Log Length: 21"
• Cast Iron Door Size (H x W): 12.5" x 23"
• Glass Viewing Area (H x W): 10" x 20"
• Flue Size: 6"
• Cast Iron Ash Grates: Standard
• Removable Ash Pan: Standard
• Circulation Blower: (Optional) 200 cfm, 3-speed
• Fireplace Color: Black
• Warranty: 5-Year Limited
• EPA Cerified: Exempt

• Circulation Blower is OPTIONAL for this fireplace

Buy Bay 2012 Freestanding Fireplace

EnergyKing Bay 2012c Model

• Overall Dimensions (H x W x D): 35" x 33" x 24"
• Required Hearth Opening (H x W x D): N/A
• Shipping Weight (approx.): 510 lbs.
• BTU Capacity* (approx.): 45,000 BTU
• Heating Area* (approx.): 1,500 Sq Ft
• Log Length: 21"
• Cast Iron Door Size (H x W): 12.5" x 23"
• Glass Viewing Area (H x W): 10" x 20"
• Flue Size: 6"
• Cast Iron Ash Grates: Standard
• Removable Ash Pan: Standard
• Circulation Blower: (Included) 200 cfm, 3-speed
• Fireplace Color: Black
• Warranty: 5-Year Limited
• EPA Cerified: Exempt

• Circulation Blower is INCLUDED for this fireplace

Buy Bay 2012c Freestanding Fireplace




Why Choose An EnergyKing Fireplace?
EnergyKing Style

It's Got Style:

EnergyKing Bay freestanding fireplaces feature an elegant 3 panel door to provide a broad view of the fire behind glass that is continually swept clean by the integrated air wash system. The removable ash pan and circulation blower system are both concealed behind the hinged lower grills so they don't detract from the fire's aesthetic appeal. Available in classic Charcoal Black, and accented with handles of contemporary polished chrome, the EnergyKing Bay freestanding fireplace can easily complement the decor of any home. Whatever your style, you can be confident that this EnergyKing Bay freestanding fireplace will provide exceptional performance and value.

Trouble Free Installation & Easy Operation

Trouble Free Installation & Easy Operation:

The EnergyKing Bay installation process is fairly simple. Following the instructions found in the owner's manual, your heating contractor can assemble and position the appliance and connect the smoke outlet to your listed, high temperature chimney. The blower is powered by a cord which plugs into a standard 110v outlet. Once the installation is complete, operation is a simple matter of building a fire and setting the burn rate using the touch sensitive draft control. Then you can sit back and enjoy the splendor of the flames!
